| Part Number | Supply Voltage Range (V) |
Supply Current © VCC=5V (per OpAmp) typ. (mA) |
Input Offset Voltage (typ/max) (mV) |
Input Bias Current typ.(nA) |
Input Common Mode Voltage Range(V) |
GBW (MHz) |
Output Current Source/Sink (mA) |
Channel # | Operating Ambient Temperature Range, Ta( ℃) |
Package Outline | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
| XHS358 | 3.0~36 | 0.5 | 2.0/5.0 | 20 | 0~(VCC -1.5) | 0.75 | 15/15 | 2 | -40 to +85 | SO-8, TSSOP-8, MSOP-8, DIP-8, TDIP-8 |
|
| XHS358A | 3.0~36 | 0.5 | 2.0/3.0 | 20 | 0~(VCC -1.5) | 0.75 | 15/15 | 2 | -40 to +85 | SO-8, DIP-8 | |
| LM2904 | 3.0~36 | 0.5 | 2.0/7.0 | 20 | 0~(VCC -1.5) | 0.75 | 15/15 | 2 | -40 to +125 | SO-8, DIP-8 | |
| LM2904A | 3.0~36 | 0.5 | 1.0/2.0 | 20 | 0~(VCC -1.5) | 0.75 | 15/15 | 2 | -40 to +125 | SO-8, DIP-8 | |
| XHS324 | 3.0~36 | 0.7 | 2.0/5.0 | 20 | 0~(VCC -1.5) | 0.75 | 15/15 | 4 | -40 to +85 | SO-14, TSSOP-14, DIP-14 | |
| XHS324A | 3.0~36 | 0.7 | 2.0/3.0 | 20 | 0~(VCC -1.5) | 0.75 | 15/15 | 4 | -40 to +85 | SO-14 | |
| LM2902 | 3.0~36 | 0.7 | 2.0/7.0 | 20 | 0~(VCC -1.5) | 0.75 | 15/15 | 4 | -40 to +125 | SO-14 | |
| LM2902A | 3.0~36 | 0.7 | 1.0/2.0 | 20 | 0~(VCC -1.5) | 0.75 | 15/15 | 4 | -40 to +125 | SO-14 | |
| XHS321 | 3.0~36 | 0.5 | 2.0/5.0 | 20 | 0~(VCC -1.5) | 0.75 | 15/15 | 1 | -40 to +85 | SOT23-5 |
